- マネージド Ethernet スイッチ
- スイッチタイプ: 12 ポート Layer 2+ switch
- ポート数: 12 10/100/1000Mbps Ethernet ports with non-blocking wire-speed performance
- オンボード・メモリ: 4 Mb パケットメモリ
Shared memory buffer with per-port & CoS memory management
- MEF
- Hierarchical MEF compliant policing & scheduling
- MEF E-Lane, E-Line, and E-Tree services
- フレームバッファ: Jumbo frame support at all speeds
- VLAN
- IEEE 802.1Q VLAN switch with 8K MACs and 4K VLANs
- Push/pop up to two VLAN tags
- Independent & shared VLAN learning (IVL, SVL)
- マルチキャスト: IPv4 and IPv6 multicast group support
- リマーキング: Dual leaky bucket policers with remarking and statistics
- Classifier
- 8 priorities and 8 CoS queues per port with strict or deficit-weighted
round robin scheduling
- Shaping/policing per queue and per port
- Storm Control: Policing with storm control and MC/BC protection
- Link Aggregation: IEEE 802.3ad
- セキュリティ: Advanced security and prioritization available though multistage
TCAM engine
- RSTP: Rapid Spanning Tree Protocol (IEEE 802.1W) and MSTP
- MIBs: Support for both WebStax and CEServices MIBs
- Power Management
- ActiPHY and PerfectReach power management
- VeriPHY cable diagnostics
- シリアルポート: 1 RS-232 port ホストインタフェース用
- 標準ケーブル: Standalone network switch, or in combination with a host computer
|
- 電源電圧
- 消費電力
- 動作温度
- 形状
- 84 x 55mm
- COM Express Mini
- 重量
- RoHS 規格適合
|
